Hello wasm-bindgen

Wasm-bindgen is a tool that simplifies communication between Rust and JavaScript. It enables calling JavaScript functions from Rust and vice versa, simplifying the transfer of data between these languages. Actually, it’s not exclusively for Rust, but Rust works best with wasm-bindgen.

“Hello, Rust!” Example

As mentioned earlier, wasm-bindgen allows us to call all functions from the browser from Rust code. Additionally, functions defined in Rust can also be used in JavaScript code.

$ cargo new --lib hello-wasm-bindgen
     Created library `hello-wasm-bindgen` package

use wasm_bindgen::prelude::*;

#[wasm_bindgen]
extern {
    #[wasm_bindgen(js_namespace = console)]
    fn log(s: &str);
}

#[wasm_bindgen]
pub fn greet(name: &str) {
    log(&format!("Hello, {}!", name));
}

Short explanation: * wasm_bindgen::prelude::* imports all necessary functions and traits to connect our functions with JavaScript. * #[wasm_bindgen] together with extern defines that a function from JavaScript is used in Rust. In this case, it’s the console.log function. #[wasm_bindgen(js_namespace = console)] defines that the function is found in the JavaScript namespace console. * #[wasm_bindgen] together with pub defines that the greet function should be exported for JavaScript. It calls the log function and outputs the text “Hello, {name}!”.

[package]
name = "hello-wasm-bindgen"
version = "0.1.0"
edition = "2021"

[lib]
crate-type = ["cdylib"]

[dependencies]
wasm-bindgen = "0.2.92"

Short explanation: * crate-type = ["cdylib"] defines that a dynamic C library is created. * wasm-bindgen = "0.2.92" defines the version of wasm-bindgen.

Now the project can be compiled for the web. Alternatives would be Webpack, Node.js, or Deno:

$ wasm-pack build --target web
[INFO]: 🎯  Checking for the Wasm target...
[INFO]: 🌀  Compiling to Wasm...
   Compiling proc-macro2 v1.0.79
   Compiling unicode-ident v1.0.12
   Compiling wasm-bindgen-shared v0.2.92
   Compiling once_cell v1.19.0
   Compiling bumpalo v3.15.4
   Compiling log v0.4.21
   Compiling wasm-bindgen v0.2.92
   Compiling cfg-if v1.0.0
   Compiling quote v1.0.35
   Compiling syn v2.0.55
   Compiling wasm-bindgen-backend v0.2.92
   Compiling wasm-bindgen-macro-support v0.2.92
   Compiling wasm-bindgen-macro v0.2.92
   Compiling hello-wasm-bindgen v0.1.0 (.../hello-wasm-bindgen)
    Finished release [optimized] target(s) in 4.42s
[INFO]: ⬇️  Installing wasm-bindgen...
[INFO]: found wasm-opt at "/usr/bin/wasm-opt"
[INFO]: Optimizing wasm binaries with `wasm-opt`...
[INFO]: Optional fields missing from Cargo.toml: 'description', 'repository', and 'license'. These are not necessary, but recommended
[INFO]: ✨   Done in 7.77s
[INFO]: 📦   Your wasm pkg is ready to publish at .../hello-wasm-bindgen/pkg.

Install wasm-pack: curl https://rustwasm.github.io/wasm-pack/installer/init.sh -sSf | sh

This has created a pkg directory containing a package.json file for project definition, the WebAssembly file, the JavaScript file, and type definitions for TypeScript.

$ wasm-objdump -x hello_wasm_bindgen_bg.wasm

hello_wasm_bindgen_bg.wasm:     file format wasm 0x1

Section Details:

Type[10]:
 - type[0] (i32, i32) -> i32
 - type[1] (i32, i32) -> nil
 - type[2] (i32, i32, i32) -> i32
 - type[3] (i32) -> nil
 - type[4] (i32, i32, i32, i32) -> i32
 - type[5] (i32, i32, i32, i32) -> nil
 - type[6] (i32, i32, i32) -> nil
 - type[7] (i32) -> i32
 - type[8] (i32, i32, i32, i32, i32, i32) -> nil
 - type[9] () -> nil
Import[1]:
 - func[0] sig=1 <wbg.__wbg_log_641153c3c7e8b3d9> <- wbg.__wbg_log_641153c3c7e8b3d9
Function[45]:
 - func[1] sig=7
 - ...
Table[1]:
 - table[0] type=funcref initial=29 max=29
Memory[1]:
 - memory[0] pages: initial=17
Global[1]:
 - global[0] i32 mutable=1 - init i32=1048576
Export[4]:
 - memory[0] -> "memory"
 - func[16] <greet> -> "greet"
 - func[22] <__wbindgen_malloc> -> "__wbindgen_malloc"
 - func[26] <__wbindgen_realloc> -> "__wbindgen_realloc"
Elem[1]:
 - segment[0] flags=0 table=0 count=28 - init i32=1
  - ...
Code[45]:
 - func[1] size=4675
 - ...
Data[1]:
 - segment[0] memory=0 size=764 - init i32=1048576
  - ...
Custom:
 - name: "producers"
Custom:
 - name: "target_features"
  - [+] mutable-globals
  - [+] sign-ext

Short explanation: * Upon import, it’s evident that the log function from JavaScript is being imported. * The greet function is exported and can therefore be called from JavaScript. * The __wbindgen_malloc and __wbindgen_realloc functions are used for memory management.

Usage in a Web Application

<!DOCTYPE html>
<html lang="en">

<head>
    <meta charset="utf-8" />
    <title>Hello wasm-bindgen</title>
</head>

<body>
    <script type="module">
        import init, { greet } from './hello-wasm-bindgen/pkg/hello_wasm_bindgen.js';
        init().then(() => {
            greet('Rust');
        });
    </script>
</body>

</html>

Further Resources

I am open to refining, expanding, or correcting the article. Feel free to provide a feedback or get in touch with me.
